| Total Power Output |
600W/650W |
| Type |
Redundant |
| Type of Power Supply |
Power Supply |
| Form Factor |
1U |
| Dimension (W x H x L) |
76 x 40 x 336 mm |
| +5V |
- |
| +12V |
50A (100-127Vac) 54.16A (200-240Vac) 54.16A (240Vdc) |
| +3.3V |
- |
| 5V Standby |
4A |
| +12V Standby |
- |
| Input Voltage Range |
600W: 100-127Vac 650W: 200-240Vac 650W: 240Vdc |
| Input Frequency Range |
50-60Hz |
| Input Current Range |
100-127Vac / 7 – 5.5A 200-240Vac / 4 – 3A 240Vdc / 4 – 3A (CCC only) |
| Output Type |
Gold Finger |
| 8Pin / 4Pin (12V) Connector |
- |
| PFC |
Yes, PMBus 1.2 support |
| Energy Efficiency |
94%+ |
| 80 Plus Certification |
80 Plus Platinum |
| Warranty |
1 year warranty |
| Product Environmental Compliance |
RoHS and REACH compliant, details available upon request |
